| Modello |
MAXX-FSAC36MB – 220 |
| Capacità |
Ton |
3 Ton |
| BTU |
36,000 BTU |
| HP |
4 HP |
| kW |
10.55 kW |
| Tipo |
Tipo a pavimento |
| Temperatura di esercizio |
16°C – 45°C |
| Temperatura ambiente |
7°C – 43°C |
| Area di applicazione |
40 – 65 m³ |
| Griglia mobile automatica |
Orizzontale |
| Flusso d’aria |
2000 m³/h |
| Riavvio automatico |
Sì |
| Movimento automatico |
Sì |
| Indicatore di temperatura |
Sì |
| Tipo di schermo del telecomando |
LCD |
| Valore EER di raffreddamento |
2.9 W/W |
| Pressione massima di scarico |
4.2 MPa |
| Pressione massima di aspirazione |
1.2 MPa |
| Tipo di compressore |
Rotativo |
| Gas refrigerante |
R410 |
| Carica di gas refrigerante |
1800 g |
| Livello di rumorosità – unità interna |
51 dB (A) |
| Livello di rumorosità – unità esterna |
54 dB (A) |
| Resistenza agli spruzzi d’acqua |
IPX 4 |
| Collegamenti tubi |
| Liquido |
9.52 mm 5/8 |
| Gas |
15.88 mm 3/8 |
| Maximum Indoor Unit – Outdoor Unit Distance |
15 meters |
| Maximum Indoor Unit – Outdoor Unit Height Difference |
5 meters |
| Caratteristiche elettriche |
| Tensione |
220~240V-1-60Hz |
| Capacità nominale |
10,550 W |
| Corrente nominale assorbita (A) |
13.6 A |
| Corrente massima assorbita (A) |
17.6 A |
| Potenza nominale assorbita (Watt) |
2986 W |
| Potenza massima assorbita (Watt) |
3882 W |
| Informazioni di spedizione |
| Product Dimensions – Indoor Unit (L x W x H) |
589 x 409 x 1938 mm |
| Product Dimensions – Outdoor Unit (L x W x H) |
355 x 875 x 980 mm |
| Package Dimensions – Indoor Unit (L x W x H) |
685 x 490 x 2050 mm |
| Package Dimensions – Outdoor Unit (L x W x H) |
490 x 950 x 1090 mm |
| Peso unità interna (netto/lordo) |
52 / 64 kg |
| Peso unità esterna (netto/lordo) |
54 / 62 kg |
| Certificazione |
ISO 9001 : 2008 |
