Capacity: 52000 – 58850 BTU/HR, 4.3-4.9 Ton
Floor standing Type
Compressor Type: Rotary
Slim Design
Night Silent Mode
Auto 4 way swing (Horizontal & Vertical)
Digital Display on Unit
Quick Cooling
Quiet Operation
Refrigerant: R07C Commercial Compressor
Commercial Compressor
Low Power consumption
50Hz-220V-1Ph (Indoor)
50HZ-380V-3ph (Outdoor)
Air Conditioning, Floor Standing ACs, Floor Standing ACs-220V/50Hz
4.3 Ton 380V-50Hz Floor Standing Air Conditioners MAXX-FSAC52SY-380V For Marine
Ref: IMPA Code – 174781, 174782
Commercial Grade Compressor
Powerful Airflow
Energy Saving Feature
Quick Cooling
User-friendly Control Panel
Concealed Function Display
Optional – Heresite Coating
Compare
Technical Specifications
| Model | MAXX-FSAC52SY-380 | |
| Capacity | Ton | 4.3 (4.9) |
| BTU/Hour | 52000 (48000 – 58850) | |
| HP | 5.78 – 6.54 | |
| kW | 15 – 17 | |
| Type | Floor Type | |
| Operating Temperature | 16°C – 45°C | |
| Ambient Temperature | 7°C – 43°C | |
| Application Area | 60 – 80 m³ | |
| Grid with Automatic Oscillation | Horizontal | |
| Air Flow | 2000 m³/h | |
| Automatic Restart | Yes | |
| Automatic Oscillation | Yes | |
| Temperature Indicator | Yes | |
| Remote Screen Type | LCD | |
| Cooling EER | 3.30 W/W | |
| Maximum Discharge Pressure | 4.5 Mpa | |
| Maximum Suction Pressure | 1.5 Mpa | |
| Compressor Type | Inverter | |
| Refrigerant Gas | R410 | |
| Refrigerant Gas Charge | 3500 g | |
| Noise Level | Indoor Unit | 52 dB (A) |
| Outdoor Unit | 60 dB (A) | |
| Splash Resistance | IPX 4 | |
| Pipe Connections | ||
| Liquid | Ф 9.52 mm (3/8”) | |
| Gas | Ф 19.05 mm (3/4”) | |
| Drain Tube Diameter | Ф DN25 (1 inch) (33.40mm) | |
| Maximum Distance Between Indoor and Outdoor Units | 15 meters | |
| Maximum Height Difference Between Indoor and Outdoor Units | 5 meters | |
| Electrical Features | ||
| Voltage | Indoor Unit | 220V-50Hz-1ph |
| Outdoor Unit | 380V-50Hz-3ph | |
| Maximum Input Current (Amp) | 20.5 A | |
| Maximum Input Power (Watt) | 5650 W | |
| Shipping Information | ||
| Product Dimensions (WxDxH) | Indoor Unit | 590 x 1830 x 405 mm |
| Outdoor Unit | 940 x 1370 x 404 mm | |
| Package Dimensions (WxDxH) | Indoor Unit | 707 x 2048 x 531 mm |
| Outdoor Unit | 435 x 1060 x 1455 mm | |
| Weight (Net/Gross) | Indoor Unit | 50 / 60 kg |
| Outdoor Unit | 101 / 105 kg | |
