Food Waste Disposer 220V Insinkerator SS200 220V For Marine


The ideal choice for large households or those who have a large amount of food waste to dispose of.

The InSinkErator Commercial Model SS200 Food Waste Disposal unit grinds your food scraps quickly, efficiently and hygienically, reducing the need to fill your kitchen bin.

Ref: IMPA Code – 175582

Power: 2 hp

Stainless Steel &Chrome-Plated Finish

Corrosion-Resistant Stainless Steel Grind Chamber.

Heavy-Duty Induction Motor with Thermal Overload Protection.

Moisture-Protected Enclosure with Controlled Motor Cooling.

Extremely Durable Shredding Elements.

Double-Tapered Timken Roller Bearings Absorb Shock.

Triple Lip Seal Prevents Motor Water Damage.

Secondary Oil Seal Protects Against Water & Grease Loss.

Compare

Power: 2 HP
Induction Motor
1725 RPM’s
3/4″ rubber mounting
Triple lip seal
Double-tapered Timken roller bearings
Corrosion-Resistant Stainless Steel
208-230/460V, 60 Hz

What’s Included: 1 Mounting/Bowl Assembly, 1 Electrical Control, 1 Syphon Breaker, 1 Solenoid Valve, and 1 Flow Control Valve. The standard Flow Control Valve will be sent with the unit unless the optional valve is specified.

SKU: 5487FB8/22-2-1-1-1-1-2-3-1-1-2-1-1-1-1-1-1-1-1-2-1-2-5 Categories: , , ,

Technical Specifications

Power Type DC
On/Off Control Integrated Air Switch
Motor Three-Phase
Operating Mode Intermittent
Lubrication Top and Bottom Flywheels Continuously Lubricated
Water Consumption 7 GPM (26.5 LPM) typical water flow
Drain Connection 2″ (50.8 mm)
Dishwasher Drain Connection Yes
Electrical Specifications
Voltage 208-230/460V
Frequency 60Hz – 3 Phase
Power 2
Current 3.6 / 4.4 / 2.2 A
Shipping Details
Dimensions (H x W) 489 x Ø 360.36 mm
Weight: Gross/Net 52.5 / 91 kg
