| Model No. |
MAXX-UPS15ONK 220CE |
| Capacity |
1500 VA / 900 W |
| Input |
| Nominal Voltage |
100/110/115/120/125 Vac |
| Input Voltage Range |
110 ~ 300 Vac (176 ~ 264 Vac @ 100% load) |
| Power Factor |
≥0.99 |
| Frequency |
| Frequency Range |
40 ~ 70 Hz (50/60 Hz Auto Detection) |
| Output |
| Output Voltage |
208/220/230/240 Vac |
| Voltage Regulation |
±1% |
| Power Factor |
0.9 |
| Output Frequency – On Line Mode |
46 ~ 54 Hz or 56 ~ 64 Hz |
| Output Frequency – Battery Mode |
(50/60 ±0.1%) Hz |
| Crest Factor |
3:1 |
| Total Harmonic Distortion (THDv) |
≤3% Linear Load
≤5% Non-Linear Load |
| Transfer Time – AC to Battery |
0 ms |
| Transfer Time – Inverter to Bypass |
4 ms (Typical) |
| Output Waveform |
Pure Sine Wave |
| Efficiency |
| AC Mode |
88% |
| Battery Mode |
85% |
| Battery |
| Battery Quantity |
2 ~ 3 |
| Capacity (Standard Unit) |
9 Ah/12 V (Optional 7 Ah/12 V) |
| Typical Charging Time |
4 hours to reach 90% capacity |
| Charging Voltage |
27.4 Vdc ±1%, 41.1 Vdc ±1% |
| Maximum Charging Current |
6 A / 12 A |
| Indicators |
| LED Indicator |
On Line Mode, Battery Mode, ECO Mode, Bypass Mode, Low Battery, Overload, UPS Error |
| LCD Indicator |
Input Voltage, Input Frequency, Output Voltage, Output Frequency, % Load, Battery Voltage, Internal Temperature, Remaining Backup Time |
| Alarm |
| Battery Mode |
One beep every 4 seconds |
| Low Battery |
One beep per second |
| Overload |
Two beeps per second |
| Error |
Continuous beep |
| Environmental Conditions |
| Operating Temperature |
0 °C ~ 40 °C |
| Storage Temperature |
-25 °C ~ 55 °C |
| Humidity |
20 ~ 95% RH @ 0 °C ~ 40 °C (Non-condensing) |
| Altitude |
<1500 m, derating required above 1500 m |
| Noise Level |
<50 dB at 1 meter |
| Shipping Details |
| Product Dimensions |
191 x 460 x 337 mm |
| Box Dimensions |
280 x 560 x 450 mm |
| Net Weight |
19.5 kg |
| Gross Weight |
21 kg |
| Standards |
| Safety |
IEC/EN 62040-1, IEC/EN 62477-1 |
| EMC |
IEC/EN 62040-2 (IEC 61000 Series) |
